SPECIFICATIONS
|
Vane Spindle Ranges
|
|
SPINDLE
|
TORQUE
RANGE
|
SHEAR STRESS RANGE
(Pa)
|
VISCOSITY RANGE
Cp (mPa · s)
|
|
V-71
|
NOT RECOMMENDED FOR USE ON LV TORQUE
|
|
V-72
|
LV
|
.188-1.88
|
104.04-1.04K
|
|
V-73
|
LV
|
.938-9.38
|
502-5.02K
|
|
V-74
|
LV
|
9.38-93.8
|
5.09K-50.9K
|
|
V-75
|
LV
|
3.75-37.5
|
1.996K-19.96K
|
|
V-71
|
RV
|
.5-5
|
262-2.62K
|
|
V-72
|
RV
|
2-20
|
1.11K-11.1K
|
|
V-73
|
RV
|
10-100
|
5.35K-53.5K
|
|
V-74
|
RV
|
100-1K
|
54.3K-543K
|
|
V-75
|
RV
|
40-400
|
21.3K-213K
|
|
V-71
|
HA
|
1-10
|
524-5.24K
|
|
V-72
|
HA
|
4-40
|
2.22K-22.2K
|
|
V-73
|
HA
|
20-200
|
10.7K-107K
|
|
V-74
|
HA
|
200-2K
|
108.6K-1.086M
|
|
V-75
|
HA
|
80-800
|
42.6K-426K
|
|
V-71
|
HB
|
4-40
|
2.096K-20.96K
|
|
V-72
|
HB
|
16-160
|
8.88K-88.8K
|
|
V-73
|
HB
|
80-800
|
42.8K-428K
|
|
V-74
|
HB
|
800-8K
|
434.4K-4.344M
|
|
V-75
|
HB
|
320-3.2K
|
170.4K-1.704M
|
|
V-71
|
5XHB
|
20-200
|
10.48K-104.8K
|
|
V-72
|
5XHB
|
80-800
|
44.4K-444K
|
|
V-73
|
5XHB
|
400-4000
|
214K-2.14M
|
|
V-74
|
5XHB
|
4K-40K
|
2.172M-21.72M
|
|
V-75
|
5XHB
|
1.6K-16K
|
852K-8.52M
|
Note:
- Pa=10 dyne/cm2
- Viscosity range is given at rotational speed of 10 RPM
- 5xHB is the highest torque range available
- Not for use with DVE Viscometers
M=1million K=1thousand Pa=pascal cP=centipoise mPa · s=millipascal · seconds
